技术参数
流量:3.2~150m3/h 扬程:5~80m
口径:50~150mm 液下深度:L=600mm~1500mm
我公司可根据用户要求进行设计制造
型 号 |
转速 r/min |
流 量 |
扬 程 |
效率 % |
轴功率 KW |
配用电机 | 汽蚀余量 2m |
||
比重r=1.00 | 比重r=1.35 | 比重r=1.84 | |||||||
50-32-125 | 2900 | 12.5 | 20 | 51 | 1.33 | Y90L-2/2.2 | Y90L-2/2.2 | I110L-4/0.55 | 2.0 |
50-32-160 | 2900 | 12.5 | 32 | 46 | 2.37 | Y100L-2/3 | Y112M-2/4 | Y132S1-2/5.5 | 2.0 |
50-32-200 | 2900 | 12.5 | 50 | 39 | 4.36 | Y132S1-2/5.5 | Y132S2-2/7.5 | Y160M1-2/I 1 | 2.0 |
50-32-250 |
1450 |
6.3 |
20 |
27 |
1.27 |
Y90L-4/1.5 |
Y100L-2/2.2 |
Y100L2/4/3 |
2.0 |
50-32-200 | 2900 | 12.5 | 80 | 33 | 8.25 | Y160M1-2/11 | Y160M2-2/15 | Y160L-2/18.5 | |
65-50-125 | 2900 | 25 | 20 | 62 | 2.2 | Y100L-2/3 | Y112M-2/4 | Y132S1-2/5.5 | 2.0 |
65-50-160 | 2900 | 25 | 32 | 57 | 3.82 | Y112M-2/4 | Y132S1-2/5.5 | Y132S2-2/7.5 | 2.0 |
65-40-200 |
2900 |
25 |
50 |
52 |
6.5 |
Y132S2-2/7.5 |
Y160M1-2/11 |
Y160M2-2/15 |
2.0 |
65-40-200A | 2900 | 23.3 | 43 | 52 | 5.13 | Y132S1-2/5.5 | Y132S2-2/7.5 | Y160M1-2/11 | |
65-40-250 |
1450 |
12.5 |
20 |
39 |
1.75 |
Y100L2/4/3 |
Y112M-4/4 |
Y132S-4/5.5 |
2.0 |
65-40-250 | 2900 | 25 | 80 | 46 | 11.84 | Y160M2-2/15 | Y160L-2/18.5 | Y200L1-2/30 | |
65-40-315 | 1450 | 12.5 | 32 | 33 | 3.3 | Y112M-4/4 | Y132S-4/5.5 | Y132M-4/7.5 | 2.0 |
80-65-125 | 2900 | 50 | 20 | 69 | 3.9 | Y132S1-2/5.5 | Y132S2-2/7.5 | Y160M1-2/11 | 2.0 |
80-65-160 | 2900 | 50 | 32 | 67 | 6.5 | Y132S2-2/7.5 | Y160M1-2/11 | Y160M2.2/15 | 2.3 |
80-50-200 |
2900 |
50 |
50 |
63 |
10.8 |
Y160M1-2/11 |
Y160M2-2/15 |
Y160L-2/18.5 |
2.5 |
80-50-200A | 2900 | 46.5 | 43 | 61 | 8.9 | Y 160M1-2/11 | Y160M2-2/15 | Y160L-2/18.5 | |
80-50-250 |
1450 |
25 |
20 |
52 |
2.62 |
Y100L2-4B |
Y132S-4/5.5 |
Y132M-4/7.5 |
2.5 |
80-50-250 | 2900 | 50 | 80 | 57 | 19.11 | Y180M-2/22 | Y200L1-2/30 | Y225M-2/45 | |
80-50-315 | 1450 | 25 | 32 | 46 | 4.7 | Y132M-4/7.5 | Y160M-4/11 | Y160L-4/15 | 2.0 |
100-80-125 | 2900 | 100 | 20 | 73 | 7.5 | Y160M1-2/11 | Y160M2-2/15 | Y160L-2/18.5 | 4.3 |
100-80-160 | 2900 | 100 | 32 | 73 | 11.9 | Y160M2-2/15 | Y160L-2/18.5 | Y200L1-2/30 | 2.5 |
100-65-200 |
2900 |
100 |
50 |
72 |
18.9 |
Y180M-2/22 |
Y200L1-2/30 |
Y225M-2/45 |
3.9 |
100-65-200A | 2900 | 93 | 43 | 71 | 15.3 | Y160L-2/18.5 | Y 180M-2/22 | Y200L1-2/30 | |
100-65-250 | 1450 | 50 | 20 | 63 | 4.3 | Y132S-4/5.5 | Y132M-4/7.5 | Y160M4/11 | 2.5 |
100-65-250 | 2900 | 100 | 80 | 65 | 32 | Y200L2-2/37 | Y225M-2/45 | Y250M-2/55 | 3.6 |
100-65-315 | 1450 | 50 | 32 | 58 | 7.5 | Y160M-4/11 | Y160M-4/11 | Y160L-4/15 | 2.0 |
100-65-315 | 2900 | 100 | 125 | 62 | 54.9 | Y250M-2/55 | Y280S-2/75 | Y280M-2/90 | 3.6 |
125-100-200 | 1450 | 100 | 12.5 | 73 | 4.66 | Y 132S-4/5.5 | Y132M-4/7.5 | Y160M-4/11 | 2.9 |
125-100-250 | 1450 | 100 | 20 | 72 | 7.56 | Y 160M-4/11 | Y 160M-4/11 | Y160L-4/15 | 2.3 |
